Description
Parameters
| Code | Hardness | Density | Tensile Strength | Elongation at Break | 100% Modulus | Tear Strength | Friction Loss | Processing
Temperature |
| Test Method | ASTM D2240 | ASTM D792 | ASTM D412 | ASTM D412 | ASTM D412 | ASTM D624 | ASTM D5963 | |
| Test Unit | Shore A | g/cm³ | MPa | % | MPa | kN/m | mm³ | ℃ |
| 1050P | 53±2 | 1.17 | 15 | 1100 | 1.2 | 50 | ≤70 | 170-190 |
Advantages
1. Wide hardness range and high temperature resistance:
Different hardness grades are available by adjusting component ratios. TPU remains good flexibility and abrasion resistance even at higher hardness.
2. Excellent mechanical strength:
Great load-bearing capacity, outstanding impact resistance and shock absorption performance.
3. Superior low-temperature resistance:
Low glass transition temperature. It stably maintains flexibility and physical properties at -35°C.
4. Good wear resistance, oil resistance, high transparency and elasticity.
5. Eco-friendly and recyclable, easy for secondary processing and reuse.
Applications
TPU raw materials are widely used for extrusion, injection molding, blow molding and calendaring processing. It can be made into films, sheets, tubes, profiles, wires & cables, adhesive materials and modified plastic compounds.
End-use Applications
1. Footwear industry: Sneaker soles, shoe insoles, anti-slip shoe accessories.
2. Consumer electronics: Phone protective cases, wearable device covers, shockproof accessories.
3. Industrial products: Hydraulic hoses, pneumatic tubes, conveyor belts, sealing parts, gaskets.
4. Automotive industry: Automotive interior parts, shock absorption components, wire harness protection sleeves.
5. Medical & daily goods: Transparent flexible parts, sanitary protective accessories, daily elastic products.
6. Sports & outdoor goods: Elastic protective gear, waterproof breathable films, outdoor protective parts.
